Surface Mount Technology (SMT) is the most commonly used PCB assembly process within the electronics industry. With SMT, components are mounted directly onto the surface of printed circuit boards, eliminating the need for through-holes and enabling higher density, smaller form factors, and automated production.
Best PCB Surface Mount Technology Assembly Services
Surface mount technology or SMT as it can also be called has become one of the most popular techniques used for mounting electrical components on printed circuit boards. This is because it is highly effective and efficient.
The truth is that not every company can render the best of SMT assembly services. This is where PCBtype comes in. We are a leading provider of surface mount technology services in China and we are committed to rendering the best of SMT services at prices that are budget-friendly.
We pride ourselves on providing high-quality, cost-effective SMT PCB assembly services that meet the highest industry standards. Our advanced equipment and experienced team ensure precision placement of even the smallest components, from 0201 chip packages to fine-pitch BGAs.
There is no doubting the fact that surface mount technology or SMT as it can also be called has become one of the most popular techniques used for mounting electrical components on printed circuit boards. This is because it is highly effective and efficient.
Get SMT PCB Assembly Quote Now
Experts in PCB Surface Mount Assembly
At PCBtype, our team of experts is well-trained and experienced when it comes to rendering surface mount technology services. Our experts understand your requirements. It is true that SMT has made it possible for highly complex electronics to be built into small packages. However, this also means that the assembly process requires more expertise and precision than ever before.
Precision Placement
High-speed pick-and-place machines capable of placing 0201 chip packages and 0.4mm pitch BGA components with extreme accuracy.
Advanced Inspection
Full AOI, X-Ray, and SPI inspection systems ensuring every solder joint meets IPC-A-610 Class II/III standards.
RoHS Compliant
Lead-free reflow process fully compliant with RoHS, REACH, and environmental regulations worldwide.
Quick Turnaround
Prototype SMT assembly in 24-72 hours. Low-to-medium volume production within 5-10 business days.
How Surface Mount Technology Works
The SMT assembly process follows a series of precise steps to ensure reliable and high-quality results:
PCB Surface Mount Assembly Standards & Compliances
One of the biggest mistakes you can make is patronizing a company that does not render services that are up to standard. The implication is that you may end up getting circuit boards that are below standard. Of course, in the long run, your business reputation will be damaged.
We render surface mount technology service that are fully compliant with all the stipulated rules and regulations. All of the circuit boards producing over the years for clients are safe. There is no need being worried since they will meet the required standards. We are ISO 9001:2015 certified and ISO 14001 certified. Our finished products are also fully RoHS-compliant.
It is also crucial to point out that our testing and inspection methods are amongst the best you will find in this industry. Be rest assured that all of your circuit boards will be made to go through Automated Optical Inspection (AOI). Some other approaches that we adopt for high quality surface mount technology assembly are Scanning Electron Microscopy, Humidity & Temperature Testing, Cross-sectioning, Specimen Preparation, and many others about the quality of your circuit boards. This is because at PCBtype, we do not compromise quality.
SMT PCB Assembly Capabilities
PCBtype has been a leader in advanced PCB assembly technology for decades. From prototype PCB assembly and low volume PCB assembly to mixed technology PCB assembly, we provide high-quality printed circuit board assembly services to customers in Europe, America, Asia, and other parts of the world.
Our advanced PCB manufacturing and assembly equipment, well-trained and experienced technicians, and production workers ensure that your difficult PCB assembly work can be completed faster and at a lower price with high quality. Our capabilities include:
| Item | Capability |
|---|---|
| Assembly Type | Single-Sided SMT, Double-Sided SMT, Mixed Technology (SMT + THT) |
| Min. Component Pitch | 0.3mm (Fine Pitch), 0.4mm (Ultra-Fine Pitch) |
| Component Size | 01005 (0402 metric) to 45mm x 45mm large ICs |
| BGA Capability | 0.25mm pitch micro-BGA, uBGA, CBGA, CCGA, LGA |
| Placement Accuracy | +/- 0.025mm at 3 sigma |
| Placement Speed | Up to 10+ components per second per machine |
| Solder Paste | Lead-free (SAC305), Leaded (Sn63Pb37) |
| Reflow Ovens | Nitrogen atmosphere, 10-zone temperature control |
| Max. Board Size | 600mm x 450mm (larger panels available upon request) |
| Layers Supported | Up to 28 layers |
| Volume Range | Prototype (1 pc) to Mass Production (100K+ units) |
| Turnaround Time | Prototype: 24-72 hours | Production: 5-15 business days |
Surface Mount Device (SMD) Types
We have extensive experience and expertise in assembling the following surface mount device:
- Ball Grid Array (BGA) — High-density interconnect for complex ICs
- Ultra-Fine Ball Grid Array (uBGA) — Micro-scale BGA for compact designs
- Quad Flat Pack No-Lead (QFN) — Exposed pad for better thermal performance
- Quad Flat Package (QFP) — Traditional gull-wing lead package
- Small Outline Integrated Circuit (SOIC) — Standard SMD package for analog/digital ICs
- Plastic Leaded Chip Carrier (PLCC) — J-leaded package for socketed applications
- Package-On-Package (PoP) — Stacked die packaging for mobile devices
- Small Chip Packages (Pitch of 0.2 mm) — Ultra-miniature passive components
SMC/SMD Packaging
- Tube — Ideal for medium-volume orders with standardized component sizes
- Tape-on-Reel — Recommended for automated high-speed placement machines
- Tray — Best for large, delicate, or irregularly shaped components
- Bulk — Cost-effective option for simple passive components
You can choose any of the SMC/SMD packaging types; however, we strongly recommend that you choose Tube or Tape-on-Reel in any case for improved surface mount speed.
Comprehensive PCBA Testing Capabilities
In order to ensure the quality of surface mount PCB assembly, we strictly implement the following PCBA testing and inspection items:
- X-ray Inspection — For hidden solder joints under BGA/QFN packages
- In-Circuit Testing (ICT) — Verifies component values and connections
- Functional Testing (FCT) — Validates board functionality under real conditions
- Burn-in Testing — Stress tests boards for reliability assurance
- Automated Optical Inspection (AOI) — Visual inspection of solder joints and component alignment
- Solder Paste Inspection (SPI) — Verifies solder paste deposit volume and alignment before reflow
- First Article Inspection (FAI) — Detailed inspection of first-off production unit
Conformal Coating
To provide high-quality PCBAs and prolong the life of circuit boards in harsh environments, PCBtype provides a range of conformal coating types and methods, including acrylic, silicone, and polyurethane. UV tracers are used to assure quality and adherence to industry standards.
Learn More about Conformal Coating Services →
Affordable Services
It is true that there are lots of companies claiming to render PCB Surface Mount Assembly Services. However, you need a company that renders such services at the most competitive prices. This is why we are existing at PCBtype. Our mission has always been to make the best PCB Surface Mount Assembly Services available to you at prices that are budget-friendly.
Prototype SMT
1-10 pcs, 24-72 hours turnaround. Ideal for proof-of-concept and design validation.
Low Volume
10-500 pcs, 5-10 days. Perfect for pre-production runs and pilot batches.
Mass Production
500+ pcs, competitive unit cost. Full turnkey solution from fabrication to assembly.
How To Order SMT PCB Assembly Service?
You should provide the PCB assembly files as follows to get the SMT PCB assembly quote:
FAQs for SMT
Surface-mount technology (SMT) is a method in which the electrical components (SMC or SMD) are mounted directly onto the surface of a printed circuit board. In contrast to traditional through-hole technology (THT), where component leads are inserted into drilled holes, SMT places components directly on the PCB surface and solders them in place using reflow ovens.
This approach enables higher component density, smaller board sizes, and fully automated assembly processes. SMT is the dominant technology used in modern electronics manufacturing.
SMT offers numerous advantages over traditional through-hole assembly:
- Higher density — Components placed on both sides of the board
- Smaller size — Enables miniaturization of electronic devices
- Lower cost — Automated placement reduces labor costs significantly
- Better performance — Shorter signal paths improve electrical characteristics
- Faster production — Fully automated process from start to finish
- Greater reliability — Fewer drilled holes means stronger PCB structure
SMD (Surface Mount Device) refers to the actual electronic components designed for surface mounting. These components have flat contacts or solder balls instead of wire leads. Examples include SOIC, QFP, QFN, BGA, and chip resistors/capacitors.
SMT (Surface Mount Technology) refers to the entire manufacturing process and methodology of mounting these SMD components onto PCBs. It encompasses solder paste printing, pick-and-place, reflow soldering, inspection, and testing.
In short: SMD = the component, SMT = the assembly process.
Yes! PCBtype offers full turnkey SMT PCB assembly services. This includes:
- PCB fabrication (single, double-sided, multilayer)
- Complete components sourcing (global supply chain network)
- SMT stencil fabrication (laser-cut, framed or frameless)
- SMT assembly (single-side, double-side, mixed technology)
- Full testing suite (AOI, X-Ray, ICT, FCT)
- Conformal coating (acrylic, silicone, urethane)
- Final packaging and worldwide shipping
You only need to provide your Gerber files and BOM — we handle everything else.
Absolutely. Quick-turn SMT assembly is one of our core strengths:
- Prototype SMT: 24-72 hours from order to shipment
- Low volume: 3-7 business days
- Medium volume: 7-14 business days
- High volume: 15-25 business days
We maintain dedicated quick-turn production lines specifically for prototype and low-volume orders, ensuring fast delivery without compromising quality.
